Bring a bold new look to your ride with the all-new ICON Alloys COMPRESSION! Combining sharp lines, a concave spoke design, and “ICON-optimized” dimensions, these wheels will increase both the form and function of your Jeep, truck, or SUV. Staying true to the ICON Alloys approach, the COMPRESSION has been engineered to maximize caliper clearance and optimize wheel position for un-hindered suspension travel and steering function. Backspace dimensions and wheel offset have been strategically developed to reduce scrub radius, improving all-around handling and ride quality and making a set of these wheels the perfect complement to an ICON Vehicle Dynamics suspension system.
KEY FEATURES:
- Application-specific dimensions optimize vehicle dynamics and tire clearance - Reduced unsprung weight and rotating mass improves on and off-road vehicle performance - Aluminum alloy construction provides strength properties that are well suited for off-road use
PART NUMBERS & DIMENSIONS:
PART # SIZEFINISH PATTERN BACKSPACE OFFSET HUB BORELOAD RATING
2017857345SB17 × 8.5SAT BLACK5 × 5” 4.5” -6mm 71.5mm2750 LBS 2017856350SB17 × 8.5SAT BLACK6 × 135 5” 6mm 87.1mm2750 LBS 2017858347SB17 × 8.5SAT BLACK6 × 5.5” 4.75” 0mm 106.1mm2750 LBS
